Waterproof IP67 Grade FTTH PLC Splitter With H Inline Female Connectors SC APC

Shenzhen Unifiber Technology Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Waterproof IP67 Grade FTTH PLC Splitter With H Inline Female Connectors SC APC

  • 1
  • 2

Brand Name : Unifiber or OEM

Model Number : PLC splitter with H inline Female connectors

Certification : ROHS

Place of Origin : China

MOQ : 10

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 500pcs/day

Delivery Time : 3~5 days

Packaging Details : Carton box

Product : PLC splitter with H inline Female connectors

Splitter Type : 1*4 or 1*8

Connector type : H inline Connector

Waterproof grade : IP67

Compatible : Corning H Optitap

Application : FTTH

Contact Now

The H inline connector end incorporates an SC/APC type connection within a female adapter on it , sealed, threaded polymer housing allowing easy connection to either a multi port terminal

Provides superior weather resistance for FTTA and other outdoor applications;
-Allows flexibility to use factory terminatedassemblies or pre-terminated or field installed assemblies;
-Suitable for FTTA and outdoor temperature extremes ;
-Ensuresfunctionality in harsh weather environments;
-Can be installs without special tooling ;
-Threaded style coupling ;
-Provides bend protection for installation and long term use.

-Compatible with Corning-OptiTap and H-Connector;
-Factory terminated for high performance;

Product name H-Connector In-line Receptacle compatible with Corning Optitap
Cable Type dielectric or Tonable
Cable diameter 5.0mm round cable or 4.5*8.1mm flat cable or 4.5*9.8mm toneable cable
Application Aerial , Direct Buried , Duct
Termination Both end or one end
Specifications - Connector A
Reflectance, Typical -65 dB
Insertion Loss, Typical ≤ 0.15 dB
Connector Type Female OptiTap connector(H-Connector In-line Receptacle)
Specifications - Connector B
Reflectance, Typical -65 dB
Insertion Loss, Typical ≤ 0.15 dB
Connector Type None or Hardend male Optitap/male H-connector
Optical Characteristics
Fiber Type Single-mode
Fiber count 1F
Fiber Category G.652.D
Wavelengths 1310 nm / 1550 nm
Maximum Attenuation 0.35 dB/km / 0.25 dB/km

Waterproof IP67 Grade FTTH PLC Splitter With H Inline Female Connectors SC APC
Waterproof IP67 Grade FTTH PLC Splitter With H Inline Female Connectors SC APC
Waterproof IP67 Grade FTTH PLC Splitter With H Inline Female Connectors SC APC
Waterproof IP67 Grade FTTH PLC Splitter With H Inline Female Connectors SC APC
